COATINGS
FINISH COATINGS
• POS-63 HASL
• LED-FREE HOT AIR SOLDER LELELING HASL LF
• IMMERSION FINISH: GOLD ENIG / SILVER / TIN
• CARBON FINISH CARBON
• ORGANIC FINISH OSP
• GOLD PLATING OF BLADE CONNECTORS GOLD FINGER
EXTRA COATINGS
• SOFT GOLD (NI ~2.5-6 МCМ / AU ~0.25-0.5 МCМ)
• HARD GOLD (NI ~2.5-6 МCМ / AU ~1.25 МCМ)
• HASL + ENIG / HASL + CARBON
• ENEPIG
| / IMC | / Flexible | / Standard | / HDI |
|---|---|---|---|
|
- POS-63 (HASL)
|
- Immersion Gold (ENIG) / Silver /Tin
|
- POS-63 (HASL)
|
- POS-63 (HASL)
|
|
- Lead-Free Soldering (HASL LF)
|
- Lead-Free Soldering (HASL LF)
|
- Lead-Free Soldering (HASL LF)
|
|
|
- Immersion Gold (ENIG)
|
- Immersion Gold (ENIG) / Silver /Tin
|
- Immersion Gold (ENIG) / Silver /Tin
|
|
|
- Carbon Coating (CARBON)
|
- Graphite Coating (CARBON)
|
||
|
- Organic Solderability Preservative (OSP)
|
- Organic Coating (OSP)
|
||
|
- Gold Finger Plating
|
- Gold Finger Plating
|
||
|
- Soft Gold (Ni ~2.5-6 µm / Au ~ 0.25-0.5 µm)
|
- Soft Gold (Ni ~2.5-6 µm / Au ~ 0.25-0.5 µm)
|
||
|
- Hard Gold (Ni ~2.5-6 µm / Au ~ 0.25-0.5 µm)
|
- Hard Gold (Ni ~2.5-6 µm / Au ~ 0.25-0.5 µm)
|
||
|
- Combined HASL+ENIG / CARBON+ENIG
|
- Combined HASL+ENIG / CARBON+ENIG
|
||
|
- ENEPIG new!
|
- ENEPIG new!
|
